NISE 105U
- Onboard Intel® Celeron® processor J1900 quad core, 2.42GHz
- Dual independent display from DVI-I and HDMI
- 2 x Intel® I210-AT GbE LAN ports; support WoL, teaming and PXE
- 2 x USB 2.0, 1 x USB 3.0
- 4 x COM ports (COM1 & COM2 with RS232/422/485, jumper-free setting)
- 1 x Optional interface for optional Wi-Fi/3.5G
- Support -10°C to 60°C operating temperature
- Support 9-30VDC input
Powered by Intel® Celeron® processor (formerly codenamed “Bay Trail”), the NISE 105U provides outstanding performance not only on computing but also on graphics, and it presents a brand new opportunity for both intelligent and industrial computing solutions. Up to 8G DDR3L memory, NISE 105U have several options on storage devices like M.2, HDD and SSD. The NISE 105U support wide DC input range from 9-30VDC. The NISE 105U has high integration ability with optional mini-PCIe module and 4 x COM ports, which makes it a real intelligent system for various applications such as factory automation applications, network applications (with optional GbE LAN, Wi-Fi, 3.5G/4G LTE module) and communication applications (with optional GPIO, RS232/422/485). NISE 105U is definitely the top choice for M2M intelligent system and factory automation platforms.
NISE105U (P/N: 10J00010522X0)
Intel® Celeron® Processor J1900 Quad Core fanless system
24V, 60W AC/DC power adapter w/o power cord (P/N: 7400060061X00)
| Date | Description | Version | OS | Download |
|---|---|---|---|---|
| 2020-04-08 | Audio | Windows | ||
| 2019-05-28 | Chipset | Windows | ||
| 2019-05-28 | Display | Windows | ||
| 2019-05-28 | LAN | Windows | ||
| 2019-05-28 | MBI | Windows | ||
| 2019-05-28 | TXE | Windows |
