NDiS B561/B561-PoE
NDiS B561/B561-PoE
Visual Edge Computer Powered by 12th Gen Intel® Core™ Processor
Main Feature:
- Support 12th Gen Intel® Core™ i7/i5/i3 socket type processor
- Intel® PCH Q670E
- Intel® integrated UHD graphic engine driven by Xe architecture
- Support 3 independent 4K@60Hz display output
- HDMI 2.1 resolution can be up to 8K@60Hz
- 1 x HDMI 2.1, 2 x HDMI 2.0
- 8 x USB 3.2
- 1 x RS-232/422/485, 3 x RS232
- NDiS B561: 1 x GbE LAN, 2 x 2.5G GbE LAN
- NDiS B561-PoE: 1 x GbE LAN, 2 x PoE (follow IEEE802.3af std)
- 3 x M.2 socket Key B/E/M
Powered by the 12th Gen Intel® Core™ processor series and Intel® 600 series chipset integrated graphics controller, the NDiS B561/B561-PoE fanless visual edge computer can handle powerful multimedia content. It can be operated in an extended operating temperature range between -20 to 60°C. Moreover, to fully satisfy customers’ expectations, there are three 4K2K independent display outputs or up to 8K@60Hz in one display output and rich connectives including 8 x USB 3.2, 3 x LAN ports (including 2 x PoE ports), Wi-Fi 6E and 4G, 5G support. The NDiS B561 can be used for both in-door and out-door applications such as visual edge computing, public transportation, security surveillance, outdoor bus station, and even smart stadium.
NDiS B561 (P/N: 10W00B56101X0)
12th Gen Intel® Core™ processor (up to 35W) fanless system, Intel® Q670E chipset
NDiS B561-PoE (P/N: 10W00B56102X0)
12th Gen Intel® Core™ processor (up to 35W) fanless system, Intel® Q670E chipset, PoE
