IPPC 1660-A11
IPPC 1660-A11
15.6” TFT HD 16:9 Heavy Industrial Panel PC with Intel® Processor N97,
P-Cap Touch Screen, 8GB DDR5, 1x PCIe slot
Main Feature:
- 16:9 15.6” HD Panel PC with P-Cap touch
- Intel® Processor N97, Quad Core 2.0GHz, 6M Cache
- 1x DDR5-4800MHz with 8GB installed by default
- Support multi- Display for DP; 1x USB-C(DP Alt. Mode)
- Dual Intel® 2.5GbE LAN ports
- 2 x USB 3.2, 2 x RS-232/422/485 with isolation(optional)
- Support 1 x M.2 Key B 2242 SSD (SATA 3.0) for storage
- Support 1 x PCIe x1 Expansion Slot
- IP66 compliant front panel
- Mounting support: panel/wall/stand/VESA (100mm x 100mm)
- DC power input 24V DC
- Support TPM 2.0
The IPPC 1660-A11 is a 15.6” HD fanless panel PC powered by Intel® N-Series processor, offering high efficiency and low power consumption. It features an IP66-rated front panel and a die-cast aluminum bezel and metal enclosure for durability, meeting IEC 61000-6-2/EN 61000-6-4 standards.
Expansion options include PCIe, Mini PCIe, and M.2 slots for add-ons like fieldbus and Wi-Fi/LTE/5G modules. It supports dual 2.5GbE connectors for fast data transfer and reliable networking, plus DP and USB-C (DP Alt. Mode) for multiple displays. Ideal for factory automation and IoT applications, the IPPC 1660-A11 combines performance, reliability, and flexibility.
Barebone
IPPC1660-A11 (P/N: 10II0166000X0)
15.6 P-Cap, N97, DDR5 8GB, 24V, 2 x USB 3.0, 2 x LAN, 1 x DP,
1 x USB-C, 1 x COM, PCIe slot
Options
24V, 60W AC/DC power adapter w/o power cord
(P/N:7400060054X00)
2 x R-S232 w/bracket (P/N: 10II0006001X0)
1x DIO (2 inputs/2 outputs) + Audio (Line out/Line in/ Mic in) (P/N: 10II0006000X0)
