FTA 5190
FTA 5190
Compact Edge Server w/ Intel® Xeon® 6 SoC Processor,
8 x 25GbE Fiber, 8 x 1GbE Copper Port, and 1 x LAN Module Slot
Main Feature:
- Intel® Xeon® 6556P-B SoC processor, TDP 215W
- 4 x DDR5 6400 ECC RDIMM, up to 128GB
- 1 x M.2 Key M 2280 NVMe SSD (PCIe 4.0/5.0)
- 2 x M.2 Key M/B 2242 SSD
- 8 x 25GbE SFP+ port
- 8 x 1GbE RJ45 port
- 1 x LAN module slot
- – Support: 1 x PCIe 4.0 x16
FTA 5190 is a compact yet powerful Edge server powered by Intel® Xeon® 6 SoC high core count CPU (formerly: Granite Rapids-D), equipped with PCIe Gen4/5 NVMe storage, it processes hot data with ease for collaboration, big data, and application-centric deployments. The form factor of FTA 5190 is optimized with a shorter depth (less than 400mm) to fit into limited space such as a wall mount rack or a telecom cabinet. With its extensive Ethernet capabilities, including eight 25GbE fiber and eight 1GbE copper ports, FTA 5190 is an innovative high-speed Ethernet AI Edge solution, delivering enhanced performance for network security, image recognition, and media analytics.
FTA 5190 (P/N: 10FT0519000X0)
1U rackmount w/ Intel® Xeon® 6556P-B SoC processor, up to 36
cores, 8 x 25GbE SFP+ port, 8 x 1GbE RJ45 port, and 1 x LAN
module slot
